FA-10 Limited Class-A Headphone Amplifier


16 Watt headphone amplifier

SKU: FA10LE Category:


The new amplifier FA-10 Limited is dedicated to friends and fans of the brand. As you know, we always strive for high sound quality and optimal cost. That is why the most popular, powerful, and affordable amplifier FA-10 served as a foundation for the creation of a new model of amplifier FA-10 Limited. Deep analysis of its most significant developments, optimization of the circuit, and used components, allowed us to get a unique signature of the amplifier sound

Changes we made

  • Upgraded the circuitry of the input and output stages to provide a more even tonal balance
  • The feedback circuit has been redesigned for a more body sound yet more transparent sound
  • Modernized printed circuit boards for the installation of MUNDORF MLYTIC AG power capacitors. This provided a more detailed and dynamic sound
  • All audio circuits use ELNA Silmic II capacitors
  • We wired internally with Neotech copper ultra-pure UPOCC wire. That had a very positive effect on the entire frequency range and provided an even cleaner and weighty sound

Memorable Gift

Each owner of the amplifier will receive a unique handmade bracelet from the last batch of steel made at the plant “Azovstal” in the beautiful city of Mariupol, which was almost completely destroyed by the invading troops. The bracelet is a symbol of the invincibility of the Ukrainian people. You can read more about this unique bracelet on the official page of the project https://u24.gov.ua/azovstal

Class A precision and speed

The FA-10 Limited amplifier circuits are employing J-Fet input stage and bipolar transistors at class A mode with a supply voltage of 80 volts of output stage all that features are providing clean transmission for signal up to 16 Watt on 32 Ohm load of output power


The FA-10 Limited offers balanced XLR and single-ended RCA audio inputs and a set of 4-pin XLR and 1/4 Jack TRS outputs. Which can be used at the same time. Three GAIN modes give you unique flexibility to use the amplifier with a wide range of headphones without loss of sound performance quality

Fine Attenuation

High transparency at any volume level and the absence of even minimal unbalance of the channels, allows you to get more accurately set the volume level thanks to the 64-step relay (by Panasonic) volume control attenuator

Clean Power

The primary foundation of the amplifier is a custom-made, low-noise powerful toroidal power transformer with a low-noise power supply

Perfect fit

Classic design unit with the milled CNC face panel with Limited inscription, will allow you to recognize this unique model from the many. FA-10 Limited is a decent unit for your desktop head-fi system


Additional information

Analog inputs

balanced XLR, single-ended RCA

Analog outputs

4-pin balanced female XLR headphone out, TRS headphone out

AMP Frequency Response

5Hz-200kHz, -3dB

Output power

300Ohm: 1.7W RMS per channel, 32Ohm: 16W RMS per channel, 600Ohm: 1W RMS per channel



Input Impedance

10kOhm (SE input), 3.3kOhm (BAL input)

Output Impedance



14dB, 20dB, 25.3dB

Power Consumption



EU-230V, US-115V


11.2lbs (5.1kg)


12.6 x 13.4 x 3.15 inch (320 x 340 x 80 mm)
