TA-212.1

$4,500.00

Out of stock

Category: Tag:

Description

The tube amplifier uses directly heated triodes 2A3 on the output stage, output transformers help with the matching of the load. For low-impedance and high-impedance headphones, several operation modes of the secondary winding of the output transformers are provided. FLUX LAB TA-212.1 amplifier builds up sufficient output power to provide high-quality gain for orthodynamic/ isodynamic headphones with low-sensitivity.

Technical Features:

  • Headphone Impedance: 16 – 600 Ω
  • Input Impedance: 50 kΩ
  • Frequency Responce: 10 Hz – 70 kHz -3dB
  • Output power: <=3W
  • SNR: 94 dB
  • Harmonic Distortion: <=0,2%
  • Power Supply: AC 230V, 50/60Hz
  • Power Input: 110 W
  • Weight: 20 kg (44 lb)

Vacuum Tubes:

  • 2 x 6SN7 driver tubes
  • 2 x 2A3 output tubes
    2 x 5U4G rectifier tube
