FA-22 Class-A Headphone Amplifier

(2 customer reviews)

$749.00

Class A headphone amplifier

Clear
SKU: FA22 Category:

Description

FLUX FA-22 is the class A headphone amplifier model which combines the high transparency, dynamics, warmth and fullness sounding, the engaging character of the sound which will not leave indifferent even the most sophisticated listeners

Features

  • Class A
  • High-power MOSFET output stage
  • Bipolar input stage
  • 64-step relay volume control attenuator
  • Premium components: Nichicon, TAKMAN, NIPPON, FUJITSU-TAKAMISAWA etc.
  • Toroidal transformer



Additional information

Weight 6.6 kg
Dimensions 46 × 42 × 18 cm
Analog inputs

balanced XLR, single-ended RCA

Analog outputs

4-pin balanced female XLR headphone out, TRS headphone out

AMP Frequency Response

1Hz-1MHz, -3dB

Output power

16Ohm : 5W RMS per channel, 32Ohm : 2.5W RMS per channel

THD

<0.001%

IMD

<0.006%

SNR

>110dB, unweighted

Crosstalk

>95dB, 20 Hz-20KHz

Output Impedance

0.1Ohm

Input Impedance

10kOhm (SE input), 20kOhm (BAL input)

Gain

High gain – 20dB, Low gain – 3.2dB, Mid gain – 13.6dB

Power Consumption

45W

Voltage

EU-230V, US-115V

Weight

11.2lbs (5.1kg)

Dimensions

12.6 x 13.4 x 3.15 inch (320 x 340 x 80 mm)

2 reviews for FA-22 Class-A Headphone Amplifier

  1. Donna Townsend

    I have had some time with the FA-22 amplifier and it has surpassed all my expectations. Very textured and present bass with vice grip like control, while still having smooth and extended highs. It pulls me into the music in a way my other very expensive amps do not. Imaging is my thing and I am transported to the venue and can see the performers in their places.

  2. Jonathan Conley (verified owner)

    The FA-22 is an involving, rewarding piece of equipment. The way the FA-22 conveys voices, instruments, the space between them, the overall acoustic is convincing! To follow individual musical strains and not to lose the perspective of the whole is so enjoyable with the FA-22. Well done, Flux Lab!!
